Deflection and Drift Limits for Steel Buildings

A steel building is designed for two different kinds of performance. Strength makes sure that no member or connection fails under the worst combination of loads. Serviceability makes sure the building works well in everyday use: roofs do not sag visibly, walls do not crack, doors keep working and cranes run smoothly. Deflection and drift limits are the main serviceability criteria, and for long, light PEB frames they often decide member sizes just as much as strength does.

Vertical deflection

Vertical deflection is how far a beam, rafter or purlin sags under load, measured at its worst point. It is usually expressed as a fraction of the span: a limit of L/180 on a 7.5 m purlin means it may deflect up to about 42 mm under the relevant service load. Larger divisors mean stiffer members. Typical starting points used in metal building practice are:

These are typical values, not rules. The project specification or the engineer of record decides the limits, which are then written into the design criteria.

Lateral drift

Drift is how far the top of a column moves sideways under wind or seismic load, expressed as a fraction of the eave height. Metal-clad buildings can accept relatively large drift because profiled steel panels tolerate movement well. Buildings with masonry walls, glazing, internal partitions fixed to the frames or overhead cranes need much less movement. Crane buildings are the most sensitive: excessive sway at the runway level changes the rail gauge and can cause the crane to bind.

Why limits must be agreed early

Changing a deflection limit after design changes the frames. Stiffer criteria mean deeper rafters, heavier columns and sometimes heavier purlins and girts, so two quotations based on different limits are not comparable. When comparing offers, check that both are designed for the same limits, the same loads and the same code. It is equally important not to ask for stricter limits than necessary: specifying L/360 for every member of a simple warehouse adds steel without making the building any better for its use.

Ponding and drainage

On flat or very low-slope roofs, deflection can create a dish where water collects. The extra water adds load, which increases the deflection, which collects more water. This is called ponding, and it is one reason PEB roofs are usually built with a definite slope such as 1:10. Where a low slope is unavoidable, the engineer checks ponding explicitly and the gutters and outlets are designed with overflow capacity.

Camber

For long-span rafters or mezzanine beams, the fabricator can build in a slight upward curve, called camber, to offset the deflection under dead load. Camber improves appearance and drainage but does not make a member stronger or stiffer under live load.
