Engineering Services · Steel Structures for Guyana
Technical Documentation You Can Rely On
A steel building is only as good as the records behind it. We deliver a complete, organised document set, from the design basis to mill certificates and inspection records, for your engineer, your authorities, your insurer and the people who will maintain the building in Guyana.
Tay Ninh, Vietnam
Engineering · Fabrication · Shipping
Destination: Guyana
A complete record of your building
- Document control
- ISO 9001:2015
- Records kept and controlled under a certified system
- Material certificates
- EN 10204 3.1
- Available per project
- Accredited fabrication
- IAS AC472
- Certificate MB-268, inspection to IBC Section 1704
- Organised dossier
- 1
- One document set for your building records
Design codes and certificates as listed in World Steel's company profile; the code for each project is agreed with its engineer of record.
Why it matters
Documents that answer questions before they are asked
Your engineer of record needs the design basis and calculations. Your local authority may ask for drawings. Your customs broker needs packing lists. Your maintenance team needs the coating specification. Your insurer may want to know who made the steel and how it was inspected.
We prepare all of this as one organised set, in English, delivered with the project and kept on file.
Who uses the documentation
- Your engineer of record and architect
- Local authorities and approval bodies
- Customs brokers and logistics providers
- Erection contractor and site supervisor
- Facility managers and insurers
What you receive
What the document set includes
Delivered progressively during the project and as a final dossier.
Calculations
Structural calculations for your engineer of record, where included in scope.
Drawings
Approved shop drawings and erection drawings at their final revision.
Bills of material and bolt lists
Quantities and weights by assembly, and bolts by connection.
Quality dossier
Mill certificates, weld and coating inspection records, and non-conformance close-out.
Shipping documents
Packing lists by container, matching the piece marks.
How we work
How documentation is built up
-
01
Design
Design basis and calculations prepared.
Technical highlight: Issued with approval drawings.
Related documents: Design package
-
02
Approval
Approved drawings recorded.
Technical highlight: Revision history kept.
Related documents: Drawing register
-
03
Production
Material and inspection records collected.
Technical highlight: At every QC hold point.
Related documents: Quality records
-
04
Shipment
Packing lists and shipping documents prepared.
Technical highlight: Match piece marks.
Related documents: Shipping documents
-
05
Handover
Final dossier compiled.
Technical highlight: Organised for your records.
Related documents: Manufacturing data record
Engineered for Guyana
Documentation for a project in Guyana
What we prepare with Guyana in mind.
Local approvals
Drawings and calculations support your locally registered engineer's submissions.
Building standardsCustoms and import
Packing lists and shipping documents help your customs broker clear the shipment.
Shipping to GuyanaLong-term care
Coating specifications and maintenance notes help protect the building in Guyana's climate.
Corrosion protectionRemote access
Documents are shared through the client portal so your team in Guyana has them when needed.
Project managementWho does what
World Steel engineers and manufactures in Vietnam and exports to Guyana. Work that has to be done in Guyana is carried out by the client or licensed local partners, with our engineers supporting them remotely.
| Service | Who performs it | Notes |
|---|---|---|
| Design, quality and shipping documentation | World Steel | World Steel engineering, QA/QC and export teams |
| Submissions to Guyanese authorities | Local partner / client | Your locally registered engineer or agent |
| Customs declarations | Local partner / client | Your customs broker |
| Local approvals and stamped drawings | Local partner / client | A locally registered engineer where Guyanese rules require it |
| Foundations and anchor bolt installation | Local partner / client | Licensed local contractor, to the anchor bolt plan |
| Erection on site | Local partner / client | Licensed local erection contractor, with World Steel drawings and remote support |
FAQ
Questions about technical documentation
Straight answers on scope, design codes, shipping and what happens in Guyana.
Ask an engineerAre calculations always included?
Calculations are provided where design is part of our scope. If your engineer of record designs the building, we provide the documents that support their design.
Will I receive mill certificates?
Yes. Mill certificates are part of the quality dossier, and EN 10204 3.1 certificates are available per project.
In what language are documents issued?
In English.
How long do you keep project records?
Project records are kept under our ISO 9001 document control, so you can ask for copies later.
